Product Name: LW800
Product Introduction: 800N Louvre Actuator
Product Features:
Applications: Natural ventilation, smoke and heat extraction.
Used to drive louvre ventilation devices.
E version / G version: Built-in thermal protection module (optional).
E version / G version: Built-in intelligent module with adjustable parameters according to window type.
E version / G version: Built-in fire mode / ventilation mode.
E version / G version: Built-in intelligent linkage module, up to 12 units can be controlled together.
G version: Built-in A/B Modbus communication port, compatible with network control systems.
Window control features: soft close, soft open, rebound release when closing, reverse on obstacle.
Technical Specifications:
| Model | LW800 (Louvre Window Opener) | Pulling Force | 800N |
| Rated Voltage | 24Vdc +25%/-15% | Thrust Force | 800N |
| Rated Current | 1.0A | Material | Aluminum alloy / Alloy steel |
| Standby Current | 1.0A | Connecting Cable | Flame-retardant cable, 2m |
| Rated Power | 24W | Max. Speed | 5.5mm/s |
| Duty Cycle | 30% | Stroke | 20mm-70mm |
| Protection Rating | IP32 | Surface Treatment | Anodized / Powder coated |
| Ambient Temperature | -25℃~75℃ | / | / |
